Kodiak

Name: Kodiak
Brand: Volt Bikes
Price: 1949 USD
Availability: InStock

Original price was: $2,499.00.Current price is: $1,949.00.

With light, nimble steering and a smooth cruiser feel, you’ll barely notice the cargo on the rear rack. With a wheelbase of 1280mm you would be able to park this bike conveniently in your apartment, garage or underground parking. Comes stock with plus-size tires Kenda 26×2.3″ for you wild riders who like to take the trail to the farmer’s market. Standard for VoltBike Kodiak is a UL 2271 Certified 19.6Ah Samsung battery and powerful hydraulic disc brakes.

Kindly be aware that the Kodiak rear rack is not configured for carrying children. If you intend to do so, you will need to install rear wheel spoke protection.

Color

BATTERY

Clear

SKU: N/A Categories: Kodiak, Trio V2, Volt Bikes Brand: Volt Bikes

Overview

750W Peak Power

BAFANG is the world’s biggest manufacturer of hub motors for e-bikes. VoltBike Kodiak is using Bafang G06 series geared motor which provides 80 N.m. max torque and up to 750w of peak power. The Bafang G06 series is remarkable for its high efficiency and power thanks to the integrated nylon planetary gears.

Samsung Battery

VoltBike Kodiak is using 48v 19.6Ah (950Wh) battery pack with Samsung INR18650-35E cells. The battery pack holds UL 2271 safety certification. Assembled by Phylion which is one of the largest battery manufacturers for ebike batteries with facilities in China, Europe and India. Samsung SDI’s Li-ion battery cells are preferred by high-end e-bike makers and companies that lead the e-bike market.

Backlit Color Display

Large practical display located in the middle of the handlebar offers real time stats such as speed, pedal assist level, battery capacity, distance traveled and current load. You can also charge your cell phone through the built-in USB connector. New for the display is the lighting sensor which atomically activates your lights when it gets dark.

Sturdy Rear Rack

Standard for Kodiak is aluminum rear rack with large bamboo platform. Rated for up to 120lbs of cargo this rack can fit any load with ease. Mounted directly on the rack is LED rear taillight with brake light functionality. Please note that this rear rack is not setup to carry child. If you plan to do so you will have to install rear wheel spoke protection.

Rigid Fork

The VoltBike Kodiak features rigid fork which offers durability under heavy load and constant and predictable steering feedback.

Step-Through Convenience

Step-through bikes are the easiest for riders to mount and dismount by simply stepping through the curved frame. VoltBike Elegant’s aluminum step-through frame offers comfortable ride and is fun and enjoyable for your everyday routine.

Hydraulic Stopping Power

Voltbike Kodiak is using Tektro Auriga hydraulic front and rear disc brakes with 180mm rotors. Tektro Auriga comp disc brakes features an open system design using non-corrosive and environment-friendly mineral oil. Features dual piston design, melt forged caliper body with automatic positioning via front or rear adapters.

Simple Controls

Our redesigned cockpit includes large easy to read color LCD screen which shows all the important information like speed, battery level and current load. Get instant power with the integrated half-twist throttle with and on/off button which helps prevent accidental activation.

Now eligible for

British Columbia Specialty Use Vehicle Incentive

The Kodiak is now eligible for the Specialty Use Vehicle Incentive (SUVI) Program, designed to provide rebates on cargo e-bikes, electric motorcycles, utility trucks, and more. If qualified, you could save up to $858 CAD on your purchase of a VoltBike Kodiak. To read more about this program and the eligibility requirements, please click the link below.

Parts Included

Our bikes ship 95% assembled with everything you’ll need to get up and running, including:

Specifications

Weight 76.0 lb
Battery 48V 19.6Ah Li-ion (950Wh) Samsung Cells. UL 2271 certified. Assembled by Phylion.
Battery Style Clip-on
Bottom Bracket Sealed cartridge, square taper, VP-BC63, 24.5mm + 154.5mm + 30mm
Brakes Hydraulic disc brakes front/rear Tektro Auriga HD-E350
Brake Lever Tektro Auriga with safety power cut
Chain KMC Rust Buster. 12.7mm pin to pin center. 124 links. Total length 1547.8mm.
Crankset Prowheel Pioneer-238AA Aluminum Alloy-6061 38T Crank, 170mm with Outer Guard
Derailleur Guard Rear Metal Derailleur Guard
Fork Rigid, 135mm dropout, 40mm offset, CrMo steel
Frame Type Step-Through
Freewheel Cassette Shimano MF-TZ500-7 Tourney Freewheel 7 Speed 14-28T
Front Light Spanninga Kendo+ LED 30 Lux
Handlebars ALLUMINUM ALLOY 31.8mm*22.2mm*680mm, 10 degree
Hubset Alloy 6061 Electric Motor
Motor 500W (750W Peak) Hub Motor
Motor Type Hub Motor
Pedals Wellgo LU-313 with reflectors
Rear Derailleur Shimano Acera RD-410 7 speed direct rear derailler
Rear Light Incandecent. Powered by the main battery and controlled from the keypad.
Rider Max Weight {“value”:300.0,”unit”:”lb”}
Rims 26″, 36 spokes
Seat Velo Plush VL-6142A
Seat Post Promax SP-311 Aluminum 6061 Alloy, 30.4mm*300mm
Shifter Type Shimano Tourney TX50R6CT Thumb Shifter Plus 7-Speed
Spokes Rear 12G, Front 13G
Stem Threadless Promax MA-596 with adjustable angle 35° – 145° , 100mm x 31.8mm bar clamp
Tires Kenda Kiniption 26×3, Wire Bead, 60 TPI casing. Diamond shaped knob design wraps from bead to bead for sidewall protection.
